It is suitable for workshops with limited factory area and multiple production processes, featuring a small size and tight turning radius, and can meet the material transfer needs in narrow passageways. The working mode is as follows: After receiving system instructions, the AGV automatically forks the bottom of the pallet and lifts it to connect with the next pallet, achieving end-to-end transfer. This model uses laser SLAM navigation and positioning and has been widely applied in industries such as automobiles and components, new energy lithium batteries, food and beverages, and household appliances.
Contact online serviceThe pallet-type unmanned forklift AGV is a logistics automation equipment, primarily used for horizontal handling, loading, and unloading of palletized goods in warehouses and workshops, enabling fully automated unmanned operations. Its core functions include:
Seamlessly integrate with the warehouse management system (WMS) to support real-time scheduling and monitoring.
Support one-click switching between manual and autonomous driving modes, balancing flexibility and emergency needs.
Tray-type unmanned forklift AGV has been widely applied in the following fields:
E-commerce logistics/third-party logistics: high-frequency inbound and outbound scenarios, improving turnover efficiency.
3C manufacturing/automotive manufacturing: material transfer on the production line, adapting to high-precision docking requirements.
Food and pharmaceutical industry: Conduct operations in a clean environment to reduce the risk of artificial contamination.
Basic Parameters | Name | Pallet-type unmanned forklift - JX-2000A |
Navigation Method | Laser SLAM Navigation | |
Drive Type | Mecanum wheel | |
Length × Width × Height (L × W × H) | 1613x735x(1940/2140/2340)mm | |
Net Weight (Including Battery) | 460kg | |
Maximum Load | 2000Kg | |
Turning Radius | 1360mm | |
Right-angle stacking space | 2350mm | |
Pallet size | 1200*1000mm / 1100*1100mm | |
Support material size | - | |
Network Communication | Wireless Wi-Fi/Optical Communication/5G | |
Ambient Temperature and Humidity Range | Temperature: 0~50℃ / Humidity: 10~90%, Non-condensing | |
IP Rating | IP20 | |
Performance Parameters | Passability (Slope / Step / Gap) | ≤5%/5mm/30mm |
Navigation Positioning Accuracy | ±5mm | |
Navigation Angular Accuracy | ±1° | |
Navigation Speed (Adjustable) | ≤1.5 m/s | |
Battery Capacity | 48V/24Ah Lithium Iron Phosphate Battery | |
Overall Endurance | 8h |
Basic Parameters | Name | Pallet-type unmanned forklift - JX-2000A |
Navigation Method | Laser SLAM Navigation | |
Drive Type | Mecanum wheel | |
Length × Width × Height (L × W × H) | 1613x735x(1940/2140/2340)mm | |
Net Weight (Including Battery) | 460kg | |
Maximum Load | 2000Kg | |
Turning Radius | 1360mm | |
Right-angle stacking space | 2350mm | |
Pallet size | - | |
Support material size | - | |
Network Communication | Wireless Wi-Fi/Optical Communication/5G | |
Ambient Temperature and Humidity Range | Temperature: 0~50℃ / Humidity: 10~90%, Non-condensing | |
IP Rating | IP20 | |
Passability (Slope / Step / Gap) | ≤5%/5mm/30mm | |
Navigation Positioning Accuracy | ±5mm | |
Performance Parameters | Navigation Angular Accuracy | ±1° |
Navigation Speed (Adjustable) | ≤1.5 m/s | |
Battery Capacity | 48V/24Ah Lithium Iron Phosphate Battery | |
Overall Endurance | 8h | |
Battery Specifications | Charging Time (10-80%) | ≤2h |
Charging Method | Manual/Automatic | |
Battery Cycle Count | 1500 cycles, Capacity ≥ 80% | |
Number of Laser Radars | 2 | |
Emergency Stop Button | √ | |
Safety Protection | Speaker | √ |
Ambient Lighting | √ | |
Anti-collision Strip | √ | |
Basic Functions | √ | |
Wi-Fi Roaming Function | √ | |
Functions | Automatic Charging Function | √ |
Autonomous Shelf Recognition | √ | |
Tracking Function | √ | |
QR Code Precision Navigation | Optional |
